Horizontal Vacuum Belt Filter 3D Video

This 3D video shows the structure, installation sequence, and working process of Hesheng horizontal vacuum belt filter. As continuous solid-liquid separation equipment, the filter is designed to complete feeding, vacuum filtration, cake washing, vacuum drying, cake discharge, and filter cloth cleaning in one automatic operation cycle.

Hesheng provides horizontal vacuum belt filter solutions for different industrial slurry conditions, with filter sizes available from 1 m² to 180 m². The equipment can be customized according to processing capacity, material characteristics, washing requirements, cake moisture targets, and site layout.

How Does the Horizontal Vacuum Belt Filter Work?

After installation and adjustment, slurry is evenly distributed onto the filter cloth through the feeding hopper. Under vacuum suction, liquid passes through the filter cloth and enters the vacuum box, then flows through the collecting hose into the vacuum tank.

The solid filter cake remains on the filter cloth and moves forward continuously. According to the process design, the cake can pass through mother liquor separation, co-current washing, counter-current washing, and vacuum drying sections. After further dewatering, the filter cake is discharged by the discharge device.

During operation, the filter cloth and rubber belt are cleaned by the washing device to maintain stable filtration performance. The belt rectifying system monitors the cloth position and corrects deviation automatically, helping the equipment run safely and continuously.

Learn More About Hesheng Horizontal Vacuum Belt Filter

Hesheng focuses on the research, development, manufacturing, and sales of solid-liquid separation equipment. The DU horizontal vacuum belt filter is suitable for continuous filtration, washing, dewatering, and automatic discharge in mining, chemical processing, metallurgy, environmental protection, FGD gypsum, tailings dewatering, and other slurry treatment applications.

If you are selecting a horizontal vacuum belt filter for your project, Hesheng can provide model selection support, technical communication, and customized solutions based on your slurry properties, capacity requirements, cake moisture target, and washing process.
